ADS SaniTite HP HIGH-PERFORMANCE PIPE

ADS is certified to the new CSA standard (CSA B182.13) for its ‘SaniTite HP’ (High Performance) pipe. SaniTite is the newest addition to the ADS family of dual wall pipe products, and has generated a significant paradigm shift on the products that are currently offered. The SaniTite HP’s unique engineered polypropylene resins and structure allows greater opportunities for the product to be specified on more storm, sanitary and high performance project applications.

SaniTite HP couples the most advanced polypropylene resin technology with highly engineered profile designs, resulting in a product with significantly greater pipe stiffness, beam strength and enhanced service life performance. SaniTite HP is manufactured utilizing a unique light grey polypropylene resin color to enhance post installation inspection. The pipe is engineered with triple-wall construction, and its smooth exterior wall design is supported by a corrugated structural core. This provides for improved stiffness and greater beam strength to minimize deflection, shed point load while also providing enhanced jobsite durability and easier backfill installation. Its smooth interior wall incorporates a dual banded, extended bell and a spigot with two gaskets for added safety. SaniTite HP is available in diameters up to 1500mm (60”). Its standard length is 6.096m (20’), with shorter lengths available for trench box, deep burial installations.

Sanitite HP pipe 12”–60” for sanitary sewer

SaniTite HP couples advanced polypropylene resin technology with a proven dual wall (12”-30”) and exclusive triple wall (30”-60”) profile design for superior performance and durability. SaniTite HP meets and exceeds typical standards for pipe stiffness and joint integrity.

Features:

• Advanced Construction
• Standard 12”-60” (300 mm-1500mm) diameters
• Varied lengths available 13’ (4.0 m), 16.3’ (4.9m) and 20’ (6.1m)
• Redundant double gasketed joints
• Inert material
• 1,000 hour 10.8 psi (74.5 kPa) joint test for 30”-60” (750 mm – 1500 mm) pipe per ASTM 2736
• Industry standards for manhole connections, testing and installation

Superior polypropylene material

Made from an engineered impact modified co-polymer compound, the superior strength and material properties of polypropylene (PP) offer robust pipe stiffness, excellent handling characteristics, and long service life when compared to traditional sanitary sewer products. It is chemically resistant to hydrogen sulfide gas and sulfuric acid concentrations typical of sanitary sewers to provide superior durability and performance. The unique light grey resin color provides superior UV resistance as well as improving the pipe’s interior visibility during post-installation inspection.

Industry standards in sanitary sewer

SaniTite HP pipe has a patented extended, reinforced bell with polymer composite bands and dual gaskets that add an additional factor of safety within each joint. The SaniTite HP joint performance exceeds the 10.8 psi (74.5 kPa) laboratory performance standards per ASTM D3212. SaniTite HP is tested to 15 psi (103.4 kPa) to provide additional redundancy and factor of safety for critical sanitary sewer installations. In the field, each section of SaniTite HP may be tested by a low pressure air test, according to ASTM F1417. ASTM F1417 is a commonly used standard for diameters 12”-36” (300 mm-900 mm) and specifies that 3.5 psi (24.1 kPa) air pressure be held for a specified length of time based upon pipe diameter and length of run. For diameters greater than 30” (900 mm) SaniTite HP joint integrity may be validated by a joint isolation test. Where an infiltration/exfiltration test is preferred, ASTM F2487 specifies a simplistic method of verifying proper joint performance. A standard tapping product, such as Inserta Tee, is compatible with SaniTite HP. Testable repair couplers are available at ADS distributor locations. PVC sleeve couplers are available for 12”-30” (300 mm-900 mm) dual wall pipe. Rubber repair couplers with stainless steel shear bands are available for 12”-60” (300 mm-1500 mm) diameters. SaniTite HP meeting ASTM F2736 and F2764 is currently manufactured in 20’ (6 m) or 13’ (4 m) lengths for diameters 12”-48” (300-1200 mm), while the 60” (1500 mm) diameter is manufactured in 20’ (6 m) and 16.3’ (5 m) lengths. The 20’ (6 m) lengths aid in speed of installation and reduce the total number of joints. However, the 13’ (4 m) lengths are complimentary for deeper projects where trench box conditions require a shorter pipe.
